Amer Stainless, located in Amman, Jordan, has made a name for itself as a top-notch manufacturer and supplier of high-quality Stainless Steel EFW (Electric Fusion Welded) Pipes. These pipes are crafted to meet strict industrial standards, ensuring they are durable, resistant to corrosion, and perform consistently well in tough environments. With cutting-edge EFW technology and a strong focus on quality control, Amer Stainless guarantees precise dimensions, a smooth surface finish, and dependable mechanical properties. Their pipes are a go-to choice in industries like oil and gas, petrochemicals, water treatment, and power generation. Thanks to their sturdy construction, long lifespan, and compliance with international standards, they are the preferred option for critical piping needs.
When it comes to Stainless Steel EFW Pipes, they are usually produced in grades like SS 304, 304L, 316, and 316L, which include chromium (18–20%), nickel (8–12%), and molybdenum (2–3% in 316) to provide outstanding corrosion resistance and durability. These pipes boast high tensile and yield strength, uniform wall thickness, and increased hardness, all thanks to controlled welding and forming processes. The EFW method ensures robust longitudinal welds, exceptional dimensional accuracy, and resistance to stress-corrosion cracking. They maintain their mechanical integrity even under high pressure, temperature, and corrosive conditions, making them a reliable choice for both industrial and structural applications.
| Range : | 1/8” NB to 36” NB, 1/4” OD to 36” OD |
|---|---|
| Outer Diameter : | 6.35 mm O.D to 114.3 mm O.D |
| Thickness : | 0.8 mm to 12.7 mm |
| Length : | up to 26 Meters |
| Specifications : | ASTM A312 / ASTM SA312 |
| Types : | As Welded, EFW, ERW |
| End : | Plain End, Beveled End |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304 | min. max. | – 0.08 | – 2.0 | – 0.75 | – 0.045 | – 0.030 | 18.0 20.0 | – | 8.0 10.5 | – 0.10 |
| 304L | min. max. | – 0.030 | – 2.0 | – 0.75 | – 0.045 | – 0.030 | 18.0 20.0 | – | 8.0 12.0 | – 0.10 |
| 304H | min. max. | 0.04 0.10 | – 2.0 | – 0.75 | -0.045 | – 0.030 | 18.0 20.0 | – | 8.0 10.5 | – |
| Element | SS 304 |
|---|---|
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
| Elongation | 35 % |
Contact us to get a quick quote for your requirement.
We perform high-quality testing on our materials before delivering them to customers. The tests performed are hardness check, chemical analysis, PMI testing, flattening tests, micro and macro examination. All necessary documents such as sales invoice, packing lists, certificates of origin, and a quality assurance letter are provided. For extra peace of mind, customers can ask for third-party inspection reports.
Yes, Stainless Steel EFW pipes can be used for underground applications due to their corrosion resistance, strength, and durability, making them ideal for transporting fluids and gases in harsh environments.
To select the right Stainless Steel EFW pipes, consider factors like the material grade, pipe size, pressure requirements, environmental conditions, and compatibility with the substances being transported. Consult with an expert if needed.
Stainless Steel EFW pipes are sized based on their nominal diameter (ND) and wall thickness, which determine their strength, pressure capacity, and suitability for various applications. Standard sizing follows industry specifications.
Common grades of stainless steel used in EFW pipe manufacturing include 304, 316, 316L, and 321. These grades offer excellent corrosion resistance, strength, and durability for various industrial applications.
Stainless Steel EFW Pipes are a go-to choice in industries that need strong, corrosion-resistant piping solutions. You’ll find them commonly used in the transportation of oil and gas, as well as in chemical and petrochemical processing, water treatment facilities, and power generation systems. These pipes excel at moving liquids, gases, and high-temperature fluids under significant pressure. They also play a vital role in HVAC systems, industrial plumbing, marine engineering, and the food processing sector. Thanks to their outstanding weld integrity and precise dimensions, they’re perfect for long pipeline installations, structural support systems, and critical industrial projects where reliability, safety, and durability are absolutely essential.
